Product Description

HTHP Jet Sample Dyeing Machine is developed for small quality dyeing. It has low liquor ratio and low consumption. The machine has short dyeing circle, and the dyeing technique is the same with big machine, it’s suitable for many kinds of fabric, and high automatic.

Product Features

1. Save water, environmental protection

2. Low liquor ratio: 1:8

3. Save steam

4. Low cost on effluent treatment.

5. Save dyes and chemicals

6. Short dyeing time

7. Suitable for many kinds of fabric

Standard Structure

1. Made of high quality anti-corrosion stainless steel

2. High efficiency anti-corrosion stainless steel centrifugal pump

3. Outside heat exchanger and filter

4. The fabric lifting roller is soft stared by inverter, and combined with reducer

5. Big capacity dosing tank

6. Fabric outing shelf

7. Water level indicator

8. Temperature controlling computer

9. Stainless steel electricity control cabinet

Optional Parts

1. Material choosing

2. Second water inletting

3. Second water outgoing

4. Mixing device for dosing tank

5. Ration charging

6. Proportion temperature rising.

7. Programmable computer

8. The main pump is pressure regulation controlled by inverter

Specification

Model	Capacity (kg)	Total Power(kw)	Dimension
			L(mm)	W(mm)	H(mm)
DB5E	4-6	5.9	1400	1170	1800
DB10E	8-15	7.7	2450	1050	2060
DB30E	20-30	9.3	3750	1200	2200
DB50E	40-60	11.2	4600	1400	2650
DB100E	80-120	11.2	6200	1700	2650
